Specifications
The correlation between published specifications and sonic quality is unreliable. A list of
numbers reveals virtually nothing. All technical measurements must be subject to quali-
tative as well as quantitative interpretation.
Measurements of the Nº380 yield excellent results by any standards. However, only those
specifications that apply to its actual operation are included here.
■ Power consumption: 40W maximum
■ Mains voltage: 100V, 120V, 200V, 220V, or 240VAC @ 50/60Hz
■ Overall dimensions: See “Dimensions”
■ Shipping weight: 35 lbs. (16 kg)
■ Inputs: 2 stereo balanced (Swiss XLR female)
4 stereo single-ended (Madrigal RCA female)
1 Mark Levinson Link communications connector
1
1
⁄8" mini-jack for external IR repeater
■ Outputs: 2 stereo record outputs (Madrigal RCA female)
1 stereo balanced main out (Swiss XLR male)
1 stereo single-ended main out (Madrigal RCA female)
1 Mark Levinson Link communications connector
■ Gain:
■ Gain range: -72.1 dB to +18.9 dB
■ Gain resolution: 0.1 dB steps above 38.8 in display (-34 dB),
gradually increasing step size at lower levels
■ Input overload: greater than 16V (0 dB output)
■ Input impedance: 100kΩ shunted by 220pF
■ Output impedance: less than 6Ω
■ Maximum output (MAIN outputs): 16V rms, balanced
