Dossier Técnico | BM1000
MOBBA PROTOCOL
Protocol used in M A.
Estrutura do pedido
STX ENQ ETX
Estrutura da resposta
STX ST P P P P P P P
Legenda
STX
Flag of beginning of message
ENQ
Request fl ag
ETX
Flag of end of message
ST
Flag of weight status:
[+] positive [-] negative [?] unstable
P
Weight
RAFELS PROTOCOL
Protocol used only on BM1000 TOP/BMX1, on 14.
When the RAFELS mode is selected, weight can be sent automatically or by request. Its operation
depends on three parameters: PZER, PMIN and PAUT.
PZER PMIN PAUT Restart Weighing
Weight below
min amount
0 1
Automatic
or Manual
Must pass through minimum weight to perform a new weighing Sim
0 1
Automatic
or Manual
First weighing is below min weight: the weight amount must
be at least 1 scale degree below min weight
Sim
1 0
Automatic
First weighing is above min weight: must go through the min
weight in order to be performed
Não
1 0
Manual
Minimal variation of weight set in PZER (min 10e), or going
through 0. It doesn’t need to be under the minimum weight.
Não
1 1
Automatic
The weight must vary at least the amount defi ned in PZER
(min 10e)
Sim
1 1
Manual
First weighing under minimum weight: the min weight amou-
nt must be at least 1 scale degree below minimum weight, or
above the value set in PZER
Sim
1 1
Manual
First weighing above min weight: the weight must vary the
amount.
Sim
