TISA PROTOCOL
This protocol can be used to get a calculated price and weight having sent the cost per kg. It is used
in Modes 3, 4 and 5 in the following logic:
MODE 3 | Only responds to requests;
MODE 4 | Sends information when stable, and responds to requests;
MODE 5 | Streams information and responds to requests.
Request
98 P P P P P C CR LF
Response
99 S W W W W W E I I I I I I C CR LF
Caption
98
Flag of the request message
99
Flaf of the response message
P
Weight
S
Flag of weight status
W
Weight
E
Addition fl ag
I
Addition
C Checksum (XOR)
CR/LF Ending characters for the weight message
METTLER PROTOCOL
Protocol used in  B.
Request
W
Response (stable weight):
STX P P P P P P CR
Response (unstable weight):
STX ? I CR
Caption
W
W character
STX
Flag of the beginning of the message
P
Weight (can include a decimal point)
? e I ? and I characters
CR
Ending character for the weight message
GRAVITON PROTOCOL
Protocol to be used in M C.
Request
NETO CR
Response (stable weight)
[ + / - ] P P P P P P P CR
Caption
NETO
N E T O characters (see table at the end for ASCII codes)
+ / -
Indication of positive or negative weight
20h | Space
P
Weight
CR
Ending character for the weight message
*
For S and E, there are two possible
responses:
0 | 30h | no error
1 | 31h | error
Every time there is a value confi rma-
tion fl ag, this is communicated using
the above symbols.
