Martin ATOMIC 3000 User Manual

DMX PROTOCOLS A
1-CHANNEL DMX MODE
3 AND 4 CHANNEL DMX MODES
Channel Value Percent Function
1
0 - 5
6 - 249
250 - 255
0 - 1
2 - 98
98 - 100
Blackout
Flash rate, slow to fast
Continuous “Blinder” effect
Channel Value Percent Function
1 0 - 5
6 - 255
0 - 1
2 - 100
Flash intensity
Blackout
Minimum to maximum
2
0 - 255 0 - 100
Flash duration
0 - 650 ms @ 50 Hz AC, or
0 - 530 ms @ 60 Hz AC
3
0 - 5
6 - 255
0 - 1
2 - 100
Flash rate
No flash (single flash with ch. 1)
0.5 - 25 Hz @ 50 Hz AC, or
0.6 - 30 Hz @ 60 Hz AC
Note: Enable channel 4 with Mode DIP switch no. 4 on.
4
0 - 5
6 - 42
43 - 85
86 - 128
129 - 171
172 - 214
215 - 255
0 - 1
2 - 16
16 - 33
33 - 50
50 - 67
67 - 84
84 - 100
Special effects
No effect
Ramp up
Ramp down
Ramp up-down
Random
Lightning
Spikes

Martin ATOMIC 3000 Specifications

General

Type	Strobe
DMX Channels	3
Control	DMX
Dimming	0-100%
Voltage	50/60 Hz
Lamp	Xenon
