Martin M2PC Safety And Installation Guide

12 © 2012 Martin Professional A/S
Martin M2GO and M2PC Safety and Installation Guide
Back panel
M2GO
DC Power IN
XLR 4-pin male
Desklight
XLR 3-pin female, 12V, 500ma for Littlite type gooseneck desklights
DMX 1-4
XLR 5-pin female DMX Outputs, RDM compatible, bidirectional for DMX
Input
USB
4 x USB-A device connections (max. 500ma.)
1 x USB-B input connection
Network
RJ45 Gigabit Remote network connection
EtherDMX
RJ45 Gigabit DMX Ethernet connection
VGA
15-pin monitor connection
HDMI
HDMI digital monitor connection
Line Out
Green 3.5mm stereo jack
Line In
Blue 3.5mm stereo jack
Mic In
Pink 3.5mm mono jack
M2PC
DC Power IN
XLR 4-pin male
Desklight
XLR 3-pin female, 12V, 500ma for Littlite type gooseneck desklights
DMX 1-2
(3+4 optional)
XLR 5-pin female DMX Outputs, RDM compatible, bidirectional for DMX
Input
USB
1 x USB-B input connection
