Service and display messages 31
• Errors are shown in the display regardless of display status: they override an inactive display and any
other information that the display might be showing.
• If an error is present, the status LED flashes red.
The possible error messages are listed in Table 5
:
Short code
Long message and explanation
BEER
BEAM SHAPER POS
Error in magnetic indexing circuit. Beam shaper position timeout reached.
BETC
BEAM TMP CUT OFF
Beam temperature sensor continuously measures temperature above maximum limit.
BETE
BEAM TMP SEN ERR
Beam temperature sensor error or no communication with sensor.
C1ER
COLORWHEEL 1 ERR
Error in magnetic indexing circuit. Color wheel position timeout reached.
CEEF
COM ERR EFFECT
Effects module communication error.
CEPT
COM ERR P/T
Pan/tilt system communication error.
CEZF
COM ERR Z/F
Zoom/focus system communication error.
CELD
COM ERR LED DRV
LED driver communication error or no communication with sensor.
COLD
FIXTURE COLD
Fixture too cold. Physical movement of effects is disabled until fixture has warmed up.
CYER
CYAN ERROR
Error in electric indexing circuit. Cyan position timeout has been reached.
DCTC
DC TEMP CUT OFF
DC PCB temperature sensor continuously measures temperature above maximum limit.
DCTE
DC TEMP SEN ERR
DC PCB temperature sensor error or no communication with sensor.
EFTC
EFF TEMP CUT OFF
DC PCB temperature sensor continuously measures temperature above maximum limit.
EFTE
EFF TEMP SEN ERR
DC PCB temperature sensor error or no communication with sensor.
FAN
BASE 1 FAN ERR
Base fan 1 error or no communication with sensor.
FAN
BASE 2 FAN ERR
Base fan 2 error or no communication with sensor.
FAN
BASE 3 FAN ERR
Base fan 3 error or no communication with sensor.
FAN
HEAD FAN 1 ERR
Base fan 1 error or no communication with sensor.
FAN
HEAD FAN 2 ERR
Head fan 2 error or no communication with sensor.
FAN
HEAD FAN 3 ERR
Head fan 3 error or no communication with sensor.
FAN
HEAD FAN 4 ERR
Head fan 4 error or no communication with sensor.
FBEP
PAN FBACK ERR
Pan position magnetic indexing system timeout. Fixture is unable to correct pan position (but
pan movement will often still be possible).
FBET
TILT FBACK ERR
Tilt position magnetic indexing system timeout. Fixture is unable to correct tilt position (but tilt
movement will often still be possible).
FG1E
FIX GOBO W 1 ERR
Error in magnetic indexing circuit. Static gobo wheel position timeout has been reached.
FOER
FOCUS ERROR
Error in electric indexing circuit. Focus position timeout has been reached.
Table 5: Error messages
