Martin MAC Quantum Profile User Manual

32 MAC Quantum Profile User Guide
The fixture reports a calibration error if valid calibration data is not detected in EEPROM. The fixture may be
unable to read/write calibration data to EEPROM.
G1ER
GOBO W 1 ERR
Error in magnetic indexing circuit. Rotating gobo wheel position timeout has been reached.
IRER
IRIS ERROR
Error in electric indexing circuit. Iris position timeout has been reached.
LDTC
LED TEMP CUTOFF
LED board temperature sensor continuously measures temperature above maximum limit.
LDTE
LED TEMP SEN ERR
LED board temperature sensor error or no communication with sensor.
MAER
MAGENTA ERROR
Error in electric indexing circuit. Magenta position timeout has been reached.
PAER
PAN ERROR
Pan position electrical indexing system timeout.
PFTC
PFC TEMP CUTOFF
Power factor correction system sensor continuously measures temperature above maximum
limit.
PFTE
PFC TEMP SEN ERR
Power factor correction system temperature sensor error or no communication with sensor.
PSER
PAN SENSOR ERROR
Fixture unable to retrieve reliable data from pan position sensor.
PTTC
PT TEMP CUTOFF
Pan/tilt PCB sensor continuously measures temperature above maximum limit.
PTTE
PT TEMP SEN ERR
Pan/tilt PCB sensor error or no communication with sensor.
R1ER
GOBO W 1 ROT ERR
Error in magnetic indexing circuit. Rotating gobo position timeout has been reached.
SLER
SAFETY LOOP
Safety loop circuit activated. A temperature circuit breaker has shut down LEDs. Circuit breaker
resets automatically after temperature has returned to normal operating range.
TIER
TILT ERROR
Tilt position electrical indexing circuit timeout.
TSER
TILT SENSOR ERR
Fixture unable to retrieve reliable data from tilt position sensor.
UEEF
UPL ERR EFFECT
Upload to Pan/Tilt error
UEZF
UPL ERR Z/F
Upload to Zoom/Focus error
UITC
UI TEMP CUTOFF
User interface (display/control panel) sensor continuously measures temperature above
maximum limit.
UITE
UI TEMP SEN ERR
User interface (display/control panel) sensor error or no communication with sensor
YEER
YELLOW ERROR
Error in electric indexing circuit. Yellow position timeout has been reached.
ZFTC
ZF TEMP CUTOFF
Zoom/focus sensor continuously measures temperature above maximum limit.
ZFTE
ZF TEMP SEN ERR
Zoom/focus sensor error or no communication with sensor.
ZOER
ZOOM ERROR
Error in electric indexing circuit. Zoom position timeout has been reached.
Short code
Long message and explanation
Table 5: Error messages
