Maruyama BC230 - Specifications

＿
US-2
＿
Product Description
SPECIFICATIONS
Model BC230
Dry Weight (kg)
※
4.4
Handle Conguration Loop Handle
Engine Displacement (cc) 22.5
Fuel Tank Capacity (L) 0.5
Carburetor Diaphragm Type
Ignition Solid State System
Spark plug NGK BPM8Y Set Gap 0.6 - 0.7 mm
Fuel Mixture
Use Only Non - Leaded Regular Gasoline.
Two - Stroke Oil Mix 25:1 Ratio Must Be Approved For Air - Cooled Engines.
※
Without Fuel, Blade and Debris shield.
1. Gearcase
2. Shaft Assembly
3. Safety Decal
4. Model Name
5. Throttle Trigger and Stop Switch
6. Attachment Ring for Shoulder Strap
7. Clutch Drum Housing
8. Engine
9. Air Filter
10. Fuel Tank
11. Throttle Cable and Stop Switch Wires
12. Shoulder Strap
13. Loop Handle
14. Debris Shield
1
2
4
3
5
6
7
8
14
13
11
12
10
9
