14 CVT
14.1 Removal
• Remove the left footrest.
• Remove the left crankcase cover.
• Loosen the driven pulley (rear belt
pulley assembly) as shown in figure 49.
Figure 49: CVT
• Then remove the rear belt pulley as
illustrated in figure 50.
Press the rear belt pulley with both hands
to remove it.
• Remove the CVT belt (toothed belt).
Figure 50: Removal of the driven pulley
