VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 12 -
7.2 Menu Parameters
 Run Mode:
Following parameters can view or change during run time.
 Immediately after powering, unit will run in Auto Mode. In auto mode channel will scan automatically according to scan
time selection (1-250 second).
 By pressing INCREMENT Key in run mode, Channel number scanning on display is stopped. By pressing increment key
again, we can change channel number manually.
 By pressing SHIFT/DECREMENT Key in run mode, relay acknowledgement can be done.
 By pressing ESCAPE Key after going into the Manual Mode unit comes back to run mode.
 Other Modes:
For entering in Menu press Enter key in RUN mode. There are total Five modes in menu. By pressing increment or decrement
key mode can be changed. To enter into any mode press enter key again.
1. Level – 1
2. Level – 2
3. Level – 3
4. Calibration Mode
5. Factory Reset Parameter
The table below show the description and menu detail of the all the modes. In general to enter into any menu or to edit sub
menu, press enter key, to change the submenu parameter press increment or decrement key. To come out from any menu
press esc key.
1. Level – 1 :
Pressing MENU key DATA window shows LVL1 (LvL1) message. Press MENU key again DATA window shows pwd (PWD)
message, press increment key twice to select password and then press MENU key to enter into Level-1. DATA window shows
SP.1 (SP.1) message and by pressing increment key, DATA window shows Set Point-1 Value. Use INC and SHIFT key to
modify value. OR press MENU key again to change Set-point 1 for Channel 2. ESCAPE KEY is used to come out SP.1
LEVEL 1
Parameter
(DATA window)
Setting name and description
Default value
Shows only
if
Symbol
Name
Pwd
(PWD)
Level-1 Password
0 to 9999
0000
-
Sp.1
(SP.1)
Target Set point-1
SetPoint-1 for All Channel
50.0
-
SP.2
(SP.2)
Target Set point-2
SetPoint-2 for All Channel
50.0
Relay group
2 is
selected
SP.3
(SP.3)
Target Set point-3
SetPoint-3 for All Channel
50.0
Relay group
1 is
selected
SP.4
(SP.4)
Target Set point-4
SetPoint-4 for All Channel
50.0
Relay group
1 is
selected
Hys
(HYS)
Hysteresis
Hysteresis for All Channel
1.0
-
Table 5 Level – 1 Parameter description
2. LEVEL – 2 :
Pressing MENU key DATA window shows LvL2 (LvL2) message. Press MENU key again DATA window shows pwd (PWD)
message, press increment key twice to select password and then press MENU key to enter into Level-2. Following parameters
can be configured in LEVEL – 2.
LEVEL 2:
Parameter
(DATA W indow)
Setting name and description
Default value
Shows only
if
Symbol
Name
pwd
(PWD)
Level-2
Password
0 to 9999
0000
-
