Masibust VT7S12E - Modbus Parameter Details for Calibration Register; Modbus Parameter Details for Read Output Status Register

VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 24 -
63
SKIP-Channel CH - 2
40063
INT
0
1
R/W
-
64
SKIP-Channel CH - 3
40064
INT
0
1
R/W
-
65
SKIP-Channel CH - 4
40065
INT
0
1
R/W
-
66
RLY Latch
40066
INT
0
1
R/W
Table 33
67
RLY Group
40067
INT
0
2
R/W
Table 27
68
Scan Rate
40068
INT
1
250
R/W
-
69
Auto CJC
40069
INT
0
1
R/W
-
70
Fix CJC
40070
INT
0
60.0
R/W
-
71
Machine ID
40071
INT
1
247
R/W
-
72
Baud Rate
40072
INT
0
1
R/W
Table 34
73
Parity/Stop Bit
40073
INT
0
3
R/W
Table 35
74
Timeout
40074
INT
10
60
R/W
-
85
Retransmission Open Sensor AO Card-1
40085
INT
0
1
R/W
Table 36
86
Retransmission Open Sensor AO Card-2
40086
INT
0
1
R/W
87
Retransmission Type AO Card-1
40087
INT
0
4
R/W
Table 37
88
Retransmission Type AO Card-2
40088
INT
0
4
R/W
89
Retransmission Direction AO Card-1
40089
INT
0
1
R/W
Table 38
90
Retransmission Direction AO Card-2
40090
INT
0
1
R/W
91
Retransmission Mapping CH-1
40091
INT
-
-
R/W
-
92
Retransmission Mapping CH-2
40092
INT
-
-
R/W
-
93
Retransmission Mapping CH-3
40093
INT
-
-
R/W
-
94
Retransmission Mapping CH-4
40094
INT
-
-
R/W
-
95
Retransmission Value AO Card-1
40095
INT
0
1
R/W
Table 39
96
Retransmission Value AO Card-2
40096
INT
0
1
R/W
98
Password
40098
INT
0
9999
R/W
-
99
Over Limit
40099
INT
0
10
R/W
-
100
Under Limit
40100
INT
0
10
R/W
-
101
Digital Filter
40101
INT
0
9
R/W
-
102
Slot
40102
INT
1
60
R/W
-
Table 19 Modbus Parameter Details for Input Register
Sr.
No.
Parameter
Absolute
Address
Parameter
Type
Min
Value
Max Value
Access
Type
NOTE
1
Calibration Password
49001
INT
0
65000
W
3
Zero Calibration Channel-1
49003
INT
-
-
W
4
Zero Calibration Channel-2
49004
INT
-
-
W
5
Zero Calibration Channel-3
49005
INT
-
-
W
6
Zero Calibration Channel-4
49006
INT
-
-
W
11
Span Calibration Channel-1
49011
INT
-
-
W
12
Span Calibration Channel-2
49012
INT
-
-
W
13
Span Calibration Channel-3
49013
INT
-
-
W
14
Span Calibration Channel-4
49014
INT
-
-
W
19
Zero Calibration AO Card-1
49019
INT
-
-
W
20
Zero Calibration AO Card-2
49020
INT
-
-
W
21
Span Calibration AO Card-1
49021
INT
-
-
W
22
Span Calibration AO Card-1
49022
INT
-
-
W
Table 20 Modbus Parameter Details for Calibration Register
 Modbus Parameter Details for Read Output Status Register:
Sr.
No
Parameter
Absolute
Address
Parameter
Type
Access
Type
1
Alarm.1 Channel-1
1
BIT
R
2
Alarm.1 Channel-2
2
BIT
R
3
Alarm.1 Channel-3
3
BIT
R
4
Alarm.1 Channel-4
4
BIT
R
5
Alarm.2 Channel-1
5
BIT
R
6
Alarm.2 Channel-2
6
BIT
R
