Masibust VT7S12E - Modbus Parameter Details for Input Register

VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 23 -
 Modbus Parameter Details for Input Register:
SR.N
O.
Parameter
Absolute
Address
Parameter
Type
Min
Value
Max Value
Access
Type
Refer
Table
1
SP.1 CH – 1
40001
INT
-
-
R/W
Table 22
2
SP.1 CH – 2
40002
INT
-
-
R/W
3
SP.1 CH – 3
40003
INT
-
-
R/W
4
SP.1 CH – 4
40004
INT
-
-
R/W
5
SP.2 CH- 1
40005
INT
-
-
R/W
6
SP.2 CH- 2
40006
INT
-
-
R/W
7
SP.2 CH- 3
40007
INT
-
-
R/W
8
SP.2 CH- 4
40008
INT
-
-
R/W
9
SP.3 CH- 1
40009
INT
-
-
R/W
10
SP.3 CH- 2
40010
INT
-
-
R/W
11
SP.3 CH- 3
40011
INT
-
-
R/W
12
SP.3 CH- 4
40012
INT
-
-
R/W
13
SP.4 CH- 1
40013
INT
-
-
R/W
14
SP.4 CH- 2
40014
INT
-
-
R/W
15
SP.4 CH- 3
40015
INT
-
-
R/W
16
SP.4 CH- 4
40016
INT
-
-
R/W
17
HYS CH – 1
40017
INT
1
250
R/W
-
18
HYS CH – 2
40018
INT
1
250
R/W
-
19
HYS CH – 3
40019
INT
1
250
R/W
-
20
HYS CH – 4
40020
INT
1
250
R/W
-
21
INPUT TYPE CH - 1
40021
INT
-
-
R/W
Table 22
22
INPUT TYPE CH - 2
40022
INT
-
-
R/W
23
INPUT TYPE CH - 3
40023
INT
-
-
R/W
24
INPUT TYPE CH - 4
40024
INT
-
-
R/W
25
Range High CH - 1
40025
INT
-
-
R/W
26
Range High CH - 2
40026
INT
-
-
R/W
27
Range High CH - 3
40027
INT
-
-
R/W
28
Range High CH - 4
40028
INT
-
-
R/W
29
Range Low CH - 1
40029
INT
-
-
R/W
30
Range Low CH - 2
40030
INT
-
-
R/W
31
Range Low CH - 3
40031
INT
-
-
R/W
32
Range Low CH - 4
40032
INT
-
-
R/W
33
Decimal Point CH - 1
40033
INT
0
3
R/W
-
34
Decimal Point CH - 2
40034
INT
0
3
R/W
-
35
Decimal Point CH - 3
40035
INT
0
3
R/W
-
36
Decimal Point CH - 4
40036
INT
0
3
R/W
-
37
RLY-Logic.1
40037
INT
0
1
R/W
Table 23
38
RLY-Logic.2
40038
INT
0
1
R/W
39
RLY-Logic.3
40039
INT
0
1
R/W
40
RLY-Logic.4
40040
INT
0
1
R/W
41
RLY-Operation
40041
INT
0
1
R/W
Table 24
42
RLY-Function.1
40042
INT
0
1
R/W
Table 25
43
RLY-Function.2
40043
INT
0
1
R/W
44
RLY-Function.3
40044
INT
0
1
R/W
45
RLY-Function.4
40045
INT
0
1
R/W
46
RLY-Delay.1
40046
INT
1
99
R/W
-
47
RLY-Delay.2
40047
INT
1
99
R/W
-
48
RLY-Delay.3
40048
INT
1
99
R/W
-
49
RLY-Delay.4
40049
INT
1
99
R/W
-
50
RLY-OpenSensor.1
40050
INT
0
1
R/W
Table 26
51
RLY-OpenSensor.2
40051
INT
0
1
R/W
52
RLY-OpenSensor.3
40052
INT
0
1
R/W
53
RLY-OpenSensor.4
40053
INT
0
1
R/W
54
RLY-Map CH - 1
40054
INT
0
2/4
R/W
Table 28
Table 29
Table 30
55
RLY-Map CH - 2
40055
INT
0
2/4
R/W
56
RLY-Map CH - 3
40056
INT
0
2/4
R/W
57
RLY-Map CH - 4
40057
INT
0
2/4
R/W
58
RLY-Type.1
40058
INT
0
2/4
R/W
Table 31
Table 32
59
RLY-Type.2
40059
INT
0
2/4
R/W
60
RLY-Type.3
40060
INT
0
2/4
R/W
61
RLY-Type.4
40061
INT
0
2/4
R/W
62
SKIP-Channel CH - 1
40062
INT
0
1
R/W
-
