Masibust VT7S12E - 1. Introduction

VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 4 -
1. INTRODUCTION
Foreword
Thank you for purchasing VT7S12E - Vibration Transmitter. This manual describes the basic functions and operation methods of
VT7S12E.Please read through this user‟s manual carefully before using the product.
This is a 8 bit controller based instrument designed for vibration type. This instrument is operated by four user-friendly keys. These
keys are used for operation and programming. The manual covers all aspects of operation of the instrument. Please read
instructions carefully before altering any programming or configuration information.
VT7S12E module operate independently and also can be connected to a data Highway or remote systems communication functions
through a personal computer or a distributed control system (DCS) using RS-485 Communication.
Notice
The contents of this manual are subject to change without notice as a result of continuing improvements to the instrument‟s
performance and functions.
Every effort has been made to ensure accuracy in the preparation of this manual. Should any errors or omissions come to your
attention, however, please inform Masibus Sales office or sales representative. Under no circumstances may the contents of this
manual, in part or in whole, be transcribed or copied without our permission.
Trademarks
Our product names or brand names mentioned in this manual are the trademarks or registered trademarks of Masibus Automation
and Instrumentation (P) Ltd. (herein after referred to as MASIBUS).
Adobe, Acrobat, and Postscript are either registered trademarks or trademarks of Adobe Systems Incorporated. All other product
names mentioned in this user's manual are trademarks or registered trademarks of their respective companies.
Version Number : 1.07 , August 2015
Checking the Contents of the Package
Unpack the box and check the contents before using the product. If the product is different from that which you have ordered, if any
parts or accessories are missing, or if the product appears to be damaged, contact your sales representative.
Product Ordering Code:
Ordering Code
Model
Channel-1
Channel-2
Power Supply
Output Type
Communication o/p
VT7S12E
X
X
X
X
X
1
Accelerometer i/p
N
None
A
85 to 265 VAC
C
4-20 mA
N
None
1
Accelerometer i/p
B
18 to 36 VDC
D
0-20 mA
1
RS485
2
Proximity i/p
E
1-5V DC
F
0-5V DC
G
0-10V DC
Table 1 Product Ordering Code
