VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 26 -
Table 27
Relay Group
Selection
Table 28
Relay Group 1
Selection
Table 29
Relay Group 2
Selection
Table 30
Relay Group 4 Selection
Modbus
Index
Parameter
Value
Modbus
Index
Parameter
Value
Modbus
Index
Parameter
Value
Modbus
Index
Parameter
Value
0
Relay Per
Group – 4
0
None
0
None
0
None
1
Relay Per
Group – 2
1
G – 1
(RELAY 1,2,3& 4)
1
G – 1
(RELAY 1 & 3)
1
G-1
(RELAY – 1)
2
Relay Per
Group – 1
2
G – 2
(RELAY 2 & 4)
2
G-2
(RELAY – 2)
3
G-3
(RELAY – 3)
4
G-4
(RELAY – 4)
Table 31
Relay Type for Group – 2
Selection
Table 32
Relay Type for Group – 4 & 1
Selection
Table 33
Relay Latch selection
Modbus
Index
Parameter
Value
Modbus Index
Parameter Value
Modbus
Index
Parameter
Value
0
Low ON
0
High/Very High
0
OFF
1
High ON
1
Low/Very Low
1
ON
2
High/LOW
Table 34
Baud Rate for Communication Selection
Table 35
Parity/Stop Bit Selection
Modbus
Index
Parameter
Value
Modbus
Index
Parameter
Value
0
9600bps
0
Parity-None/Stop Bit - 1
1
19.2kpbs
1
Parity-None/Stop Bit - 2
2
Parity Odd/Stop Bit – 1
3
Parity Even/Stop Bit – 1
Table 36
Retransmission
OPEN sensor Selection
Table 37
Retransmission
Type Selection
Table 38
Retransmission Direction
Selection
Table 39
Retransmission
Value Selection
Modbus
Index
Parameter
Value
Modbus
Index
Parameter Value
Modbus
Index
Parameter
Value
Modbus
Index
Parameter
Value
0
Down
0
0 – 20 mAmp
0
Reverse
0
Minimum
1
Up
1
4 – 20 mAmp
1
Direct
1
Maximum
2
0 – 5V
3
1 – 5V
4
0 – 10V
