VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 28 -
 RETRAMISSION OUTPUT TABLE FOR OPEN /OVER CONDITION :
RETRASMISSION
VARIABLE
SCALE
ACTION
OPEN
OVER
ERROR
4-20 mA
PV
UP
DIR
21.6
20.8
-
PV
DOWN
REV
20.8
3.2
-
PV
UP
REV
2.4
3.2
-
PV
DOWN
DIR
2.4
20.8
-
Table 41 Retransmission Output during Open/Over Condition
NOTE: -
 For Retransmission output type 0-20mamp, 0-10v, 1-5v and 0-5v also applicable according to above table.
 Also, 0-20mamp, 0-10v and 0-5v minimum output value will be 0mamp and 0v respectively.
