VIBRATION TRANSMITTER-VT7S12E
Ref No: mVTD/om/201
Issue No: 02
User’s Manual - 20 -
NOTE:
* means normal condition after abnormal has occurred
** means ack pressed in abnormal condition
*** means ack pressed in normal condition after abnormal has already occurred.
**** means it remains in the previous state. If previous state is ON then it will remain ON and the same case for OFF condition.
Pressing Shift/Decrement key for 3 seconds, acknowledgement will be given for alarm and trip relay in abnormal condition.
Alarm Latch function applicable only for ALARM, there is no affect when TRIP Selected as a relay function LEVEL – 2.
