Root Chapter 2- Setting Up
www.masimo.com 27
Masimo
To connect to a Nurse Call System
1. Identify the Nurse Call connection end (1/4 inch round female connector)
of the cable.
2. Insert the Nurse Call connection cable securely into the compatible port on
Root.
3. Depending on the connection type of the Nurse Call System, it may be
necessary to orient the other end of the Nurse Call connection cable to fit
correctly into the system connection.
4. For more information, see Device Output.
