www.masimo.com 81
Masimo
Chapter 10- Specifications
This chapter contains specifications of Root.
For information on the specifications of Radical-7, Radius-7, MOC-9 modules, and
standalone devices, see Instructions for Use or Operator's Manuals for these devices.
Electrical
Root
AC Power
requirements
100-240 VAC~, 47-63 Hz, 65 W (Max)
Fuses (2)
2 Amp, Fast Acting, Metric, (5x20mm), 250V, 1500A
Breaking Capacity
Battery
Type 10.8V Lithium Ion (Nominal)
Capacity 4 hours*
Maximum Charging
Time
4 hours
*This represents approximate run time at the lowest brightness, using a fully
charged battery.
Environmental
Root
Operating Temperature 32°F to 122°F (0°C to 50°C)
Transport/Storage Temperature -40°F to 158°F (-40°C to 70°C)
Operating Humidity 10% to 95%, non-condensing
