Masimo Root RDS7A - Wireless Specifications

Root Chapter 10- Specifications
www.masimo.com 84
Masimo
Wireless Specifications
Communication (Wi-Fi)
Type WLAN Radio: IEEE 802.11 a/b/g
Frequency
802.11a: 5180-5240 MHz, 5745-5825 MHz
802.11b/g: 2412-2462 MHz
Max Peak Output Power WLAN 17 dBm
Classification of Output
Power Rating
Conducted
Output Power Type Fixed at the Factory
Modulation Types OFDM, BPSK, CCK
Modulation Signals Analog and Digital
Available Data Rates
802.11a - 6, 9, 12, 18, 24, 36, 48, 54 Mbps.
802.11b - 1, 2, 5.5, 11 Mbps.
802.11g - 6, 9, 12, 18, 24, 36, 48, 54 Mbps.
Communication (Bluetooth)
Type Bluetooth
Frequency 2402-2480 MHz
Max Peak Output Power Bluetooth 1.3 dBm
Classification of Output
Power Rating
Conducted
Output Power Type Fixed at the Factory
Modulation Types DH5
