Root Chapter 10- Specifications
www.masimo.com 83
Masimo
Alarms
Visual Alarm Priority System Status Light Color
High Red
Low Yellow
Nurse Call Specifications
The Nurse Call relays have the following electrical specifications per switch:
Parameter Specification
Max Voltage 36 VDC or 24 VAC peak
Connectors
Connector Type Number of Ports
Ethernet 10/100 MBps 1
Nurse Call 1/4 inch round female 1
MOC-9 Masimo Connector 3
USB USB 2.0 2
Iris RS-232/RJ-45 4
