Root Chapter 3- Operation
www.masimo.com 61
Masimo
Alarm
Source
Example Explanation
Window
Level
The example shown here is a "High
Impedance" alarm in the lower Window.
Note that the border of the Window
illuminates red, and the explanation of
the alarm is shown at the top of the
Window (High Impedance Detected).
System
Level
The example shown here is a "Low
Battery" alarm. Note that the border of
the entire Root display is illuminated
red, and the explanation of the alarm is
shown in the Status Bar (Low Battery).
For more details about specific alarms on Radical-7,Radius-7 and MOC-9 modules,
see Instructions for Use or Operator’s Manuals for Radical-7,Radius-7 and MOC-9
modules.
