Periodic Maintenance and Adjustment 8-14
1. Speedometer sensor 2. final gear oil
3. Correct oil level
NOTE:
The oil level should be at the brim of the filler
hole.
3. If the oil is below the brim of the filler hole,
add sufficient oil of the recommended
type to raise it to the correct level.
CAUTION:
1. Be sure no foreign material enters the
final gear case.
2. Please clean the sensor every 320 mile
period.
3. Install the oil filler bolt, and then tighten it
to the specified torque.
Tightening torque:
Final gear oil filler bolt:
17 ft·lbf (23 Nm, 2.3 m·kgf,)
