Operation 6-13
with a bathroom scale. Put the tongue of
the loaded trailer on the scale with the
tongue at hitch height. Adjust the load in
the trailer, if necessary, to reduce the
weight on hitch. If you are carrying cargo
and towing a trailer, include the tongue
weight in the maximum vehicle load limit.
MAXIMUM LOADING LIMIT
● Vehicle loading limit (total weight of
cargo, operator, passenger and
accessories, and tongue weight):
882 lb (400Kg)
● Cargo bed:350 lb (159Kg)
● Trailer hitch:
Pulling load (total weight of trailer
and cargo): 1,212lbf (550Kgf)
Tongue weight (vertical weight on
trailer hitch point): 110lbf (50Kgf)
● Load cargo in the cargo bed as close to
the center of the vehicle as possible and
tie it down using the cargo hooks
equipped on the cargo bed.
● Tie down cargo securely in the trailer.
