Periodic Maintenance and Adjustment 8-30
1. Brake pad wear indicator groove
NOTE:
The wheels need to be removed to check the
brake pads. (See pages 8-38-8-40 for wheel
removal and installation procedures.)
Rear brake pad check
Each brake pad is provided with wear
indicator grooves, which allow you to check
the brake pad wear without having to
disassemble the brake. To check the brake
pad wear, check the wear indicator grooves.
If a brake pad has worn to the point that the
wear indicator grooves have almost
disappeared, have a service center replace
the brake pads as a set.
1. Brake pad wear indicator groove
