Masterclock GMR1000 User Manual



MasterclockGMRUserManualv2–2016.12
13
TCG:TIMECODEGENERATORMODULE
 ReadsSMPTE24,25,30‐fpsnon‐dropframeandSMPTE29.97dropframe,IRIG‐B(AandEoptional),
amplitudemodulatedandpulsewidthcoded(un‐modulated)
 Timecodesignalaccuracy:200nanosecond
 Single‐endedunbalancedordifferentialbalancedoutputs
 DB9breakoutadapteravailablefordifferential
balancedoutput(GMR1000only,notneededonGMR5000)
 Programmabledelayoffsetwith1µSresolution

PPS(PULSEPERSECOND)OUTPUT
 5VTTL(Transistor‐TransistorLogic)levelsignallockedtothemostaccuratetimereference
 AccuracycomparedtotopofsecondofGPSreference:±70nanoseconds
 RisingedgeofthePPSsignalprovidesthe“ontime”mark
 StandardonGMR5000

PPO:PROGRAMMABLEPULSEOUTPUT
 Pulseintervalanddurationcanbeselectedviasoftwarefrom100μsto3days
 Pulseoutputis5Vppfromalowimpedancesource
 Pulsewidthselectablefrom10μsecondsto100msec
 Accuracyissameasthecurrentreferencesource(i.e.GPS,timecode,NTP,
etc.)

10MHZSINEWAVEFREQUENCYINPUTANDOUPUT
 9VPeaktoPeakunloadedat50Ohm,6VPeaktoPeakwithhighimpendenceloadat50Ohm

SYNC‐IN
• SynctoPPS,PPMorPPHinput

PROGRAMMABLEDRYCONTACTRELAY(24VDC,250MA)
 Singleevent(daily)programmablerelayschedule
 StandardonGMR5000

