DRYCONTACTRELAYANDPROGRAMMABLERELAYEVENT
 ACorDCrelaythatcanbeusedineitherNO(normallyopen)modebyconnectingtopins2and3ofJ9orNC
(normallyclosed)modebyconnectingtopins1and2ofJ9ontherearoftheunit.
 Bydefault:Therelaywillactuate
toindicatewhentheunithaslostsynchronization(lock)withtheexternal
timereference.
 Therelaycanbeprogrammedtoactuateatasingletime(definedasHH:MM:SSstarttime)foraspecified
duration(inseconds)onceperday.
 StandardonGMR5000

FRONTPANELDISPLAY
 Six‐digitfrontpanelLEDdisplaymaybeorderedwithyourGMR1000toprovidethetime/datedisplay.
 Athirteen‐digitLEDdisplayisstandardontheGMR5000.

Caution:Nouser‐serviceablepartsareinsidetheGMR.PleasecontactMasterclockSupportif
yourequireserviceorrepairbyemailingsupport@masterclock.comorcalling(636)724‐3666.

 
