“OL” shown on
the display
Overrange
Indication
Overload Protection:
400 mA/600 V FAST fuse (for protection for "INPUT" terminal inputs)
10 A/600 V FAST fuse (for protection for "10A" terminal inputs)
Max. Allowable Input Current: 10 A
(For inputs > 2 A: duration < 10 secs, interval >15 minutes)
NOTE: The 10 A range is accurate from 20 to 100% of range.
Overload Protection:
400 mA/600 V FAST fuse (for protection for "INPUT" terminal inputs)
10 A/600 V FAST fuse (for protection for "10A" terminal inputs)
Max. Allowable Input Current: 10 A
(For inputs > 2 A: duration < 10 secs, interval >15 minutes)
Frequency Range: 40 – 400 Hz
Response: Average, calibrated in RMS of sine wave
NOTE: The 10 A range is accurate from 20 to 100% of range.
AC CURRENT
Range
400 A
4000 A
40 mA
400 mA
4 A
10 A
0.1 A
1.0 A
0.01 mA
0.1 mA
1 mA
10 mA
± (1.8% + 10)
± (2.5% + 10)
Resolution
Accuracy
model no. 052-0052-2 | contact us 1-800-689-9928
15
TECHNICAL SPECIFICATIONS
