CONTINUITY TEST
1.
2.
3.
4.
5.
Connect the black test lead to the "COM" terminal and the red
test lead to the "INPUT" terminal.
Set the function switch to / position.
Press the button until the display shows " ".
Connect the test leads across the circuit to be tested.
The display shows the resistance value. If the resistance is less
than about 20 , the built-in buzzer will sound. If the resistance
is between 20 and 150 , the buzzer may or may not sound.
If the resistance is more than 150 , the buzzer will not sound.
NOTE:
Before test, disconnect all power to the circuit to be tested and
discharge all capacitors thoroughly.
model no. 052-0052-2 | contact us 1-800-689-9928
25
OPERATING INSTRUCTIONS
