3.
4.
5.
6.
7.
8.
9.
"Hz %" Button
Used to switch the meter between frequency and duty cycle
measurements when the rotary switch is in the "Hz/%" position.
" " Button
Used to switch the meter between:
Function/Range Switch
Used to select the desired function or range as well as to turn on
or off the meter.
To save battery power, set this switch to the "OFF" position
when the meter is not in use.
"10A" Terminal
Plug-in connector for the red test lead for current
(400 mA - 10 A) measurements.
"COM" Terminal
This "COM" terminal is a plug-in connector for the black test
lead for all measurements except temperature measurements.
It is also a plug-in connector for the negative plug of a K type
thermocouple for temperature measurements.
"INPUT" Terminal
This "INPUT" terminal is a plug-in connector for the red test
lead for all measurements except temperature measurements
and current measurements ≥ 400 mA.
It is also a plug-in connector for the positive plug of a K type
thermocouple for temperature measurements.
"REL" Button
Used to enter/exit Relative mode.
AC current and DC current measurement functions.
Diode and continuity test functions.
Fahrenheit and celsius measurements.
8
INTRODUCTION
