MasterCraft csx 220 User Manual

ma r i sta r 200, X -2
42
27
26
25
24
23
22
14
05
04
11
20
19
21
03
16
28
31
33 34
37
01 Bow cleat
 02 Bowllercushion(where equipped)
03 Stereo CD Player (inside glove box, where equipped); Sirius
Satellite Radio (where equipped)
04 Glove box
05 Nav/anchor light
06 Walk-thru seat (where equipped)
07 Batteries (including ON-OFF switch)
08 Amp (where equipped)
 09 Hand-heldreextinguisher(beneath observer seat)
10 Heated observer seat (where equipped)
11 Center drain plug
12 Cooler (located under seat)
13 Cockpit table mount (where equipped)
14 Ski pylon
 15 Fueltankller
16 Stern cleat
17 Ballast thru-hull vent
18 Wake adjustment plate (located under swim platform, where
equipped)
19 Swim platform
20 Engine exhaust
21 Transom rail with tow eye
22 Transom drain plug (center beneath swim platform)
23 Under-platform ladder (where equipped)
24 Transom stereo remote (where equipped)
25 Underwater lights (two where equipped under swim platform)
26 Nav/anchor light (if equipped with tower, the light will be in
center aft of tower)
27 Shower wand and switch/Slick Boot wand and switch (where
equipped, inside compartment)
28 Engine compartment
29 Bilge thru-hull vent
30 Stern cleat
 31 Automaticreextinguisher
32 Subwoofer
33 Heated seat (where equipped)
34 Armrest stereo remote
35 Shift/throttle control
36 Steering wheel
37 Fire suppression unit manual override
38 Nav/anchor light
39 Instrument panel (details elsewhere in this section)
40 Circuit breaker panel (on kick panel beneath instrument panel)
41 Ballast thru-hull vent
42 Bilge thru-hull outlet
43 Adjustable mirror
44 Bow cleat
 45 Ballasttanklocatedbeneathoorboard 
Boats may also be equipped with towers (standard on X-2),
which may include stereo speakers, lights and/or
tower-mounted mirror
Storage space is located:
Under observer’s seat
Under bow seating
Under aft and wrap-around seating
Under port and starboard sun pads
mastercraft 2010 ow n e r ’s m anual • page 4-6
07, 08, 09, 10
36
01
02
29
32
35
18
06
12
15
17
30
38
39
40
41
13
43
44
45
