mastercraft 2010 ow n e r ’s m anual • page 4-17
me asur e men ts
In calculating the amount of weight, you must also take into consideration the weight of the gasoline and any ballast added. e weight of
gasoline is approximately 5.8 to 6.5 pounds (U.S.) per gallon, depending upon the weather and other factors, including the addition of ethanol,
which is slightly denser and will add very slightly to the overall weight. Water pumped into the ballast system will add 8.3 pounds (U.S.) for every
gallon added.
Overloading a boat may cause it to become unstable and may potentially result in the boat’s flotation system becoming overwhelmed. Too much
weight can sink any boat! Within this Manual and on a label mounted in each boat, except in the 280 and 265 models, is the weight limit for that spe-
cific model. Bear in mind that total weight limits include water ballast, gear brought onto the boat, additional options and all people. Equally critical
is how weight is distributed throughout the boat. If too much weight is placed in one area it can have serious impact on maintaining control. Items
and people can also shift positions during operation, potentially causing a dangerous situation.
ProStar 190
Length of Boat ........................................ 19’8”
Width Amidship ..........................................91”
Boat Weight ...................................... 2,620 lbs.
Length of Boat w/Platform ................... 21’6”
Towing Length .............................................22”
Towing Width ........................................... 100”
Fuel Capacity ...................................28 gallons
Total Weight Capacity ....................................
............................... 7 people or 1,087 lbs.
ProStar 197, X-7
Length of Boat ........................................ 19’8”
Width Amidship ..........................................91”
Boat Weight ...........................2,800-3,070 lbs.
Length of Boat w/Platform ................... 21’6”
Towing Length ..............................................22’
Towing Width ........................................... 100”
Fuel Capacity ...................................28 gallons
Total Weight Capacity ....................................
............................... 7 people or 1,087 lbs.
ProStar 214, X-14
Length of Boat ........................................ 21’4”
Width Amidship ..........................................96”
Boat Weight ...........................3,100-3,300 lbs.
Length of Boat w/Platform ................... 23’8”
Towing Length ......................................... 24’4”
Towing Width ........................................... 100”
Fuel Capacity ...................................40 gallons
Total Weight Capacity ....................................
.............................11 people or 1,525 lbs.
ProStar 214V, X-14V
Length of Boat ........................................ 21’4”
Width Amidship ..........................................96”
Boat Weight ...............................3,400 lbs. est.
Length of Boat w/Platform ................... 23’8”
Towing Length ......................................... 24’4”
Towing Width ........................................... 100”
Fuel Capacity ...................................34 gallons
Total Weight Capacity ....................................
.............................11 people or 1,450 lbs.
X-1
Length of Boat ........................................ 20’7”
Width Amidship ..........................................90”
Boat Weight ...................................... 3,200 lbs.
Length of Boat w/Platform ................... 22’6”
Towing Length ......................................... 22’3”
Towing Width ..............................................96”
Fuel Capacity ...................................33 gallons
Total Weight Capacity ....................................
.............................11 people or 1,615 lbs.
MariStar 255, X-55
Length of Boat ........................................ 25’5”
Width Amidship ....................................... 102”
Boat Weight ...........................4,850-5,000 lbs.
Length of Boat w/Platform ................... 27’8”
Towing Length ......................................... 31’2”
Fuel Capacity ...................................90 gallons
Total Weight Capacity ....................................
.............................18 people or 3,000 lbs.
X-Star
Length of Boat ........................................ 24’9”
Width Amidship ....................................... 100”
Boat Weight ...................................... 4,250 lbs.
Length of Boat w/Platform ................... 24’6”
Towing Length ..............................................24’
Towing Width ........................................... 100”
Fuel Capacity ...................................57 gallons
Total Weight Capacity ....................................
.............................12 people or 1,770 lbs.
MariStar 280, X-80, 280 STS
Length of Boat ........................................ 28’3”
Width Amidship ....................................... 114”
Boat Weight ................... 6,200 lbs./6,420 lbs.
Length of Boat w/Platform ................... 28’3”
Towing Width ........................................... 114”
Fuel Capacity .................................100 gallons
Total Weight Capacity .....................................
.......... Yacht certied; no capacity rating
CSX 220
Length of Boat ........................................ 21’5”
Width Amidship ....................................... 102”
Boat Weight ...................................... 4,300 lbs.
Length of Boat w/Platform ................... 23’7”
Fuel Capacity ...................................46 gallons
Total Weight Capacity ....................................
.............................12 people or 1,595 lbs.
CSX 265
Length of Boat ........................................ 26’5”
Width Amidship ....................................... 114”
Boat Weight ...................................... 7,750 lbs.
Length of Boat w/Platform ................... 29’2”
Fuel Capacity .................................125 gallons
Total Weight Capacity ....................................
.......... Yacht certied; no capacity rating
MariStar 200, X-2
Length of Boat .............................................20’
Width Amidship ..........................................96”
Boat Weight ...........................3,350-3,500 lbs.
Length of Boat w/Platform ................... 22’1”
Towing Length ......................................... 22’9”
Towing Width ........................................... 100”
Fuel Capacity ...................................45 gallons
Total Weight Capacity ....................................
.............................11 people or 1,609 lbs.
MariStar 215, X-15
Length of Boat ........................................ 21’8”
Width Amidship ....................................... 100”
Boat Weight ...........................3,425-3,575 lbs.
Length of Boat w/Platform ................... 23’9”
Towing Length ......................................... 24’1”
Fuel Capacity ...................................45 gallons
Total Weight Capacity ....................................
.............................14 people or 2,325 lbs.
MariStar 230, X-30
Length of Boat ........................................ 22’5”
Width Amidship ....................................... 102”
Boat Weight ...........................3,900-4,120 lbs.
Length of Boat w/Platform ................... 24’8”
Towing Length ..............................................24’
Fuel Capacity ...................................60 gallons
Total Weight Capacity ....................................
.............................16 people or 2,475 lbs.
MariStar 235, X-35
Length of Boat ........................................ 23’5”
Width Amidship ....................................... 102”
Boat Weight ...........................4,650-4,900 lbs.
Length of Boat w/Platform ................... 25’3”
Towing Length ......................................... 25’8”
Fuel Capacity ...................................60 gallons
Total Weight Capacity ....................................
.............................16 people or 2,400 lbs.
MariStar 245, X-45
Length of Boat ........................................ 24’2”
Width Amidship ....................................... 102”
Boat Weight ...........................4,730-4,950 lbs.
Length of Boat w/Platform ................... 26’4”
Towing Length ......................................... 26’1”
Towing Width ........................................... 100”
Fuel Capacity ...................................90 gallons
Total Weight Capacity ....................................
.............................18 people or 2,928 lbs.
