MasterCraft MAXIMUM 055-6768-8 User Manual

15
TM
TOOLS NEEDED FOR ASSEMBLY
TM
SUPPLIED NOT SUPPLIED
Blade wrench
Star-head screwdriverAdjustable wrench
Combination square
Slotted screwdriver
COMBINATION SQUARE MUST BE TRUE
Should not gap or overlap when square is flipped over (see dotted figure).
Should not gap or overlap when square is
flipped over (see dotted figure).
Draw light line on
board along this edge.
Straight edge or a 3/4 in. board, this
edge must be perfectly straight.
5 mm hex wrench

MasterCraft MAXIMUM 055-6768-8 Specifications

General

Brand	MasterCraft
Model	MAXIMUM 055-6768-8
Category	Saw
Language	English
