50
model no. 055-6768-8 | contact us 1-800-689-9928
OPERATION
• Grasp the trigger switch handle (2) and pull
the cutting head assembly forward until the
centre of the saw blade is over the front of
the workpiece (3).
• Engage the trigger to turn the saw on.
• When the saw reaches full speed, slowly
push the saw handle down, cutting through
the leading edge of the workpiece (3).
• Slowly move the trigger switch handle back
towards the fence, completing the cut.
• Release the trigger and allow the blade to
stop spinning before raising the cutting
head and removing the workpiece (3).
CUTTING BOWED MATERIAL (Fig. 45)
The table insert may be removed for this
purpose, but always reattach table insert prior
to performing a cutting operation. A bowed
workpiece (1) must be positioned against
the fence and secured with a hold-down
clamp (2) as shown before cutting. Do not
position workpiece incorrectly or try to cut the
workpiece without the support of the fence.
This will cause the blade to bind and could
result in personal injury.
WARNING:
To avoid injury from materials being thrown, always unplug the saw to
avoid accidental starting and remove small pieces of material from the
table cavity underlying the table insert.
Fig. 45
1
2
