REPLACEMENT PARTS

I.D. NO. Description Size Q’ty I.D. NO. Description Size Q’ty

0HUR BALL BEARING 1 3FJE CLEVIS PIN 1

0HUZ BALL BEARING 1 3FJF LOCK KNOB 6# 1

0HVK BALL BEARING 1 3FJM MOTOR COVER 1

0HX9 NEEDLE BEARING 1 3FJR GEAR BOX 1

0J6H FLAT WASHER 1 3GGC COMPRESSION SPRING 1

0JEA C-RING 1 3GGU OIL CAP 6# 1

0JEC C-RING 1 3GGW FLOW GUIDE 1

0JG7 PARALLEL KEY 1 3GGX MOTOR REAR COVER 6# 1

0JX2 HEX.-SOC SET SCREW M5*0.8-6 2 3GH6 HALL SENSOR ASS’Y 1

0K6X CR.-RE. TRUSS HD. SCREW 2 3GX7 ARM 1

0KCP CR.RE. PAN HEAD TAPPING & M5*12-60 2 3H48 ARMATURE ASS’Y 1

WASHER SCREW 3H49 CONTROLLER ASS’Y 1

0QM2 BRUSH HOLDER ASS’Y Φ27*26.5 2 3H5A NEEDLE ROLLER 2

0QQT BRUSH ASS’Y 2 3H5C OIL PAPER 1

0QR0 BRUSH COVER 2 3H7F FIELD ASS’Y 1

20ZA C-RING 1 3H9V LEAD WIRE ASS’Y 1

2RUY BALL BEARING 1 3HHY CR.RE. PAN HD. TAPPING SCREW M5*16-25 2

33NE MAGNET 1 3HJ2 CR.RE. PAN HD. SCREW & WASHER M5*0.8-60 4

35V0 BEARING BUSHING 6# 1 3HJN HEX. SOC. HD.CAP SCREWS M5*0.8-25 4

3FJ6 CUTTER SHAFT 1 3HJR HEX. SOC. TRUSS HD. SCREW M5*0.8-10 1

3FJ7 COLLAR 1 3HJS HEX. SOC. TRUSS HD. SCREW M4*0.7-6 4

3FJ8 HELIX GEAR 1 3HK5 FLAT WASHER φ5*16-2 1

3FJA GEAR SHAFT 1 3JDW PARALLEL KEY 1

3FJB STRAIGHT BEVEL GEAR 1 3JDY CR.RE. PAN HD. TAPPING SCREW M4*16-8 1

3FJD FRONT HOUSING 1
