12/75-3, 12/100-3, 24/40-3, 24/60-3 – User and Installation Manual
4.2.9 Events
With MasterBus a device can be programmed to initiate an action at another connected device. This is done by means of
event based commands.
Value Meaning
Factory
setting
Value range
Events
Event x
source
Event-based command.
ChargeMaster Plus event that should result in an action by
another device on the MasterBus network.
Disabled
(see Event source list,
section 4.2.10)
Event x
target
Select a connected MasterBus device that should take action
due to a ChargeMaster Plus event.
Selectable targets are
system dependent
Event x
command
Action to be taken by the target device. See command list in
selected device manual
Event x data Data is linked to the command.
On changes the status to On at the first signal.
Off changes the status to Off at the first signal.
Copy lets the status follow the input.
Copy Invert lets the status follow the opposite of the input
Toggle changes the status at the 1
st
signal and back at the 2
nd
signal. It is used in combination with a pulse switch.
Off, On, Copy, Copy Invert,
Toggle
Event x+1 The next event appears after enabling Event x. Disabled See Event x.
4.2.10 Events source
The ChargeMaster Plus can be configured as an event source. An event source can be used to initiate an event command and
an event action by another device that is connected to the MasterBus.
Event sources Description
Device state State of the ChargeMaster Plus serves as an event source
Bulk Bulk state of charge serves as an event source
Abs Absorption state of charge serves as an event source
Float Float state of charge serves as an event source
Failure Any fault condition of the ChargeMaster Plus serves as an event source
4.2.11 Event target
The ChargeMaster Plus can be configured as an event target by other devices on the MasterBus network. When the
ChargeMaster Plus is configured as an event target by another device, this device can initiate an event command and an
event action to be performed by the ChargeMaster Plus.
Charger on Command to switch on the ChargeMaster Plus
Bulk Command to start the Bulk state of charge
Abs Command to start the Absorption state of charge
Float Command to start the Float state of charge
Suspend charging When using a Li-ion battery MLI Ultra, programming this event is obligatory. Refer to the
manual of the Li-ion battery MLI Ultra.
