CombiMaster 120V Series – User and Installation Manual
Value
Meaning
Default
Adjustable Range
Absorption
Voltage
Absorption voltage
14.25 /
28.50V
12-15 / 24-30V
Minimum time
Minimum time that the charger stays in
absorption phase
15 min
0-600 min
Maximum time
Maximum time that the charger stays in
absorption phase
240 min
0-600 min
Return Amps
Return amps (% of maximum charge
current)
6%
0-100%
Float
Voltage
Float voltage
13.25 /
26.50V
12-15 / 24-30V
Return to Bulk
s
Delay time before the charger returns to
Bulk after reaching the Return to Bulk
voltage
30 s
0-600sec
Return to Bulk
V
Bulk return voltage. If the battery voltage
has dropped below this voltage, the
charger will return to bulk phase
12.80 /
25.60V
12-15 / 24-30V
AC IN
AC IN support
Option to enable AC input support mode
Off
On, Off
Voltage range
AC voltage input window
Wide
Wide, narrow
AC IN limits
AC IN Limit A
Fuse pre-setting A
6A
0-30A
AC IN Limit B
Fuse pre-setting B
10A
0-30A
AC IN Limit C
Fuse pre-setting C
16A
0-30A
Dry contact (installer level)
Function
Select dry contact alarm function
Alarm, Power level
Power Level
Inverter output power level
60%
0-100%
Delay on
Delay on
5s
0-300 seconds
Delay off
Delay off
5s
0-300 seconds
DIP Switches
1234567890
Position of the DIP switches
0
0,1
 Parameters marked with a  are not available in CZone.
5.2.5 Events – System automation
A CZone/MasterBus device can be programmed to initiate an action at another connected device. This
is very helpful in automation of your system but is not required. In MasterBus this is done by means of
event based commands. In the Events tab you can program the CombiMaster Inverter/Charger to act
as an event source. Events which occur during the operation of the CombiMaster Inverter/Charger will
then trigger actions from other products. The following parameters are shown in MasterAdjust.
Field
Meaning
Value
Event x source
Select an event that triggers an action, e.g. Battery pre low.
See Event source list
Event x target
Select the device that should take action, e.g. the
generator.
System dependent
Event x command
Select the parameter that must be changed on the target
device, e.g. Activate.
See command list of the
selected device
Event x data
Data, e.g. On, is linked to the command.
Off, On, Copy,
Copy Invert, Toggle
Table 1: MasterBus event parameters
