Mass Combi Ultra 12/3000-150, 24/3500-100, 48/3500-50 – User and Installation Manual
OVERVIEW MASS COMBI ULTRA
Figure 0-1: Overview of the Mass Combi Ultra
1. Display with front switch
6. Mains AC input terminal (“MAINS”)
11. Fan (3x)
2. Main battery negative
7. Generator AC input terminal (“GEN”)
12. Ground stud
3. Main battery positive
8. AC output 1 (“OUT-1”)
13. Sync connector (2x)
4. Secondary battery positive (“SEC”)
9. AC output 2 (“OUT-2”) (switched)
14. Temperature sensor connector
5. Solar DC terminal (“SOLAR”)*
10. DIP switch units (2x8)
15. MasterBus connector (2x)
* Models 12/3000-150 and 24/3500-100 only
