Using the FixAdvisor
™
VIEWING OEM ENHANCED DTCs
46 MD70
2. An “instructional” message shows on the
FixAdvisor’s display. Perform test
procedures as appropriate.
If the Continuous Memory or KOEO
test was selected, turn the ignition OFF,
then back ON. Press the ENTER
button to start the test.
- A “One moment please” message
displays while the test is in progress.
If the KOER test was selected, press
the ENTER
button to continue.
- A “One moment please” message
displays while the test is in progress.
- Turn the steering wheel to the right,
then release.
- Press and release the brake pedal.
- Cycle the overdrive switch (if
equipped).
If the FixAdvisor fails to link to the
vehicle’s computer, a “Linking Failed”
message shows on the FixAdvisor’s
display.
- Verify the ignition is ON, then press
the POWER/LINK
button to
continue.
3. To read the display:
Refer to DISPLAY FUNCTIONS on page 11 for a description
of LCD display elements.
A visible icon indicates that the
FixAdvisor is being powered through
the vehicle’s DLC connector.
The upper right hand corner of the
display shows the number of the code
currently being displayed, the total
number of codes retrieved.
The Diagnostic Trouble Code (DTC) and
related code definition are shown in the
lower section of the LCD display.
I/M MONITOR STATUS icons are not displayed when
viewing enhanced DTCs.
In the case of long code definitions, a small arrow is
shown in the upper/lower right-hand corner of the code
display area to indicate the presence of additional
information. Use the
and buttons, as
necessary, to view the additional information.
