MAXIMUS User's Manual
2.1.3 Docking Station
24
25
No. Name Descriptions
24 Charging port
Align the charging port located on the bottom of the
MAXIMUS with it and make sure the MAXIMUS main
unit is rmly sitted on the docking station.
25
Jack for power
cord
Insert the power cord for docking station into this jack.
2.2 Diagnostic Connector
OBD 2 16 PIN connector
Micro USB port
Communication indicator*2
Power indicator*1
