Operating and Testing Procedures
Now that the unit has been installed,wired and programmed,you can test each zone for
operations,and begin to educate your client on how to use their new Matrix Audio device.
At each zone,test for zone on/ off,volume,source selection,bass/ treble setting,and function
key programming.Make sure each speaker in the zone is working.
Basic keypad Functions
On/Off
Pressing the ON key momentarily will activate,or deactivate the zone.The red LED beside the
ON button should light,and you may hear the audio source playing,or you may need to select
a source and adjust the volume before the source can be heard.When the zone has been
powered on for the first time,the LED’s beside each source will cascade until one has been
selected.If you do not get any lights,or do not hear audio sources make a note of the
condition and refer to the troubleshooting section of this document.
The ON button also performs the function of ALL ZONES OFF.This is useful when you desire
to shut all components off regardless of which zone is active.To perform this function,press
and hold the ON button for a few seconds to send the appropriate command to the MRC- 8e/
8.4e.
Source Select & Treble/Bass
Try to select all of the sources by momentarily pressing the source keys.The LED beside the
selected source should light,and you will be switched to that audio source,and the program-
mable function keys will take on the properties of that particular devices keypad program.
If you do not get any lights,or do not hear audio sources make a note of the condition and
refer to the troubleshooting section of this document.
The source key also performs a secondary function.Pressing the source key and holding for a
few seconds will put the keypad into a mode to change the treble and bass settings for that
zone.See the associated diagram for the keypad function while in this mode.
