Cabling
Dead Zones
There is power at the source,and source devices and MRC-8e/8.4e seem to be powering up
OK,but one or more of the zones are not working.Check each zone keypad and press the ON
button,and look for the ON LED,or source LED’s to light.
LED does not light
You are not getting power and command connectivity to the zone.
Possible Causes
• Zone connectors at MRC-8/8.4e not secure
• Connector at Keypad to MRC-8/8.4e not secure
• Wiring standard not followed (Ensure the centre two wires are in the same
orientation at the MRC-8e/8.4e,and the keypad.They may be inadvertently reversed
in the installation)
• Input and output connectors on keypad reversed
LED does light
You are getting power and command connectivity to the zone.Check other zones and select
each source to determine if this is specific to a source,or the room in general.If the problem
is in a particular room,then there may be an issue with cabling to your speakers,or the
keypad itself.
If you get similar results for a particular source in multiple zones,then there may be an issue
with the source equipment,and you should check to see that the selected source is‘playing’.
If every other zone is ok,check to make sure cables to the speakers are secure,and that you
have tried to increase the volume level in that zone.
