4
Table of Contents
19 Placement Of The Remote:
19 The Most Important Indicator
21 Special Commands
23 Step-by-Step Programming Of Special Keys
25 Step-by-Step Program For Basic / Advanced Commands
26 Operating And Testing Procedures
26 Basic Keypad Functions
26 On / Off
26 Source Select & Treble/ Bass
27 Volume Controls
27 Programmable Keys
28 Zone Groupings
29 Troubleshooting
30 Power
Power Connections
Power Switches
Fuses
31 Cabling
Dead Zone
Led Does Not Light
Led Does Light
31 Source Connections
33 Programming
34 Special Wiring Configurations
34 Remote Amplifier Configuration
35 Keypad 2 Wire Control Only Configuration
36 Split Zone / AnalogueVolume Control (Option 1)
37 Split Zone / AnalogueVolume Control (Option 2 Multiple Control Keypads)
38 Shared Speakers – Priority Selection
39 Multiple Keypads In Zone
40 Null Modem Cable
41 RS 232 Interface Specifications & Command Reference
42 MRC- 8e/ 8.4e Specifications
42 Features
42 Technical Information
