CHAPTER 10: CONSOLE SPECIFICATIONS AND ASSEMBLY GUIDE
10.2 RFID INSTALLATION
MAIN COMPONENT LIST OF RFID SET (PART NUMBER #1000375103)
FIGURE A
Item
Part number
Description
Qty
1 1000355790 Reader;;;GAT-RM310 3.0;V3.1.1.0/V1.2;;EP 1
2 1000355791 Antenna board;;;GAT-MAXI LA 3.0;;;EP614C; 1
3 1000355754 Foam Tap;singleside;;EVA 46x60x5t;;EP614 2
4 1000354656 Signal CONN;;;;;;;700(IPEX,MHF37+JST,ZHR 1
5 1000309516 Tape;;;40x10x0.2;;EP614 4
6 004350-AB SCREW;BH;M3X0.5PX6L;;PH;;;;BP 2
2. 7XE / 7XI RFID INSTALLATION
