Matrix E7XI-01 User Manual

100
9.8 DRIVE AXLE SET REPLACEMENT - CONTINUED
22) Use a screwdriver to remove the iron plate from the drive axle (Figures S & T).
23) Re-install the belts as outlined in Sections 9.5 and 9.6.
24) Test the Suspension Elliptical as outlined in Section 9.23.
FIGURE TFIGURE S
CHAPTER 9: PART REPLACEMENT GUIDE
