Matrix E7XI-01 User Manual

76
CHAPTER 8: TROUBLESHOOTING
8.16 TV TROUBLESHOOTING - ENTERTAINMENT KEYPAD ISSUES
ENTERTAINMENT KEYPAD IS NOT WORKING
1) SYMPTOM:
a. The entertainment keypad (Figure A) is not responding.
2) SOLUTION:
a. Remove the console and check the connection of the entertainment keypad (Figure B).
b. If the entertainment keypad cable is pinched, kinked, or cut replace the keypad. Regardless of the condition, it is recommended that the
keypad cable be unplugged, then re-installed and retested prior to replacement.
c. If replacing the keypad does not resolve the issue, replace the console.
FIGURE A
FIGURE B
