10 Matrix ETERNITY NE Quick Start
Ethernet WAN
• Use the RJ45 Ethernet cable supplied for the Ethernet Port of ETERNITY to connect the
system to the IP network, which may be Public Internet or a LAN.
If connecting to the Public IP Network,
• Plug one end of the RJ45 Ethernet cable into the Ethernet Port of ETERNITY NE and the other
end into the Broadband Router/Modem.
ISDN
IP
LAN Switch
/Hub
Ethernet
WAN
DSL Modem/
Router
Computer
