4 Matrix ETERNITY NE Quick Start
This is an electronic device. Protect yourself from shock hazards. Never handle the product in power
ON condition. Always wear an electrostatic discharge prevention wrist strap/belt and use a
grounding mat when handling the product.
Protect the ETERNITY NE from heavy voltages entering from CO trunk and Extension lines.
Install Primary Protection Modules (PPM) with Gas Discharge Tubes (GDT) and fuses on entry points
for all trunk lines and extensions.
ETERNITY NE contains a 3VDC/18mAh (Li-Al) alloy-Manganese Dioxide Coin Battery (ML 1220 -
Rechargeable) of diameter 12.5mm and height 2.0mm. Battery should be replaced only by
authorized dealers of Matrix. There is a risk of explosion if the Battery is replaced in an incorrect
manner. Please dispose-off used Batteries.
For Safety Instructions, see “Protecting ETERNITY NE and Yourself” in the System Manual.
Getting Started
• Unpack ETERNITY NE and verify the package contents. In case, any of the items is missing or
damaged, contact your Dealer/Distributor.
Package Contents
•ETERNITY NE
• Two self tapping screws and screw grips for wall mounting
• Power Adapter 24VDC, 2.5Amp
• Ethernet cable
• USB Flash Drive
• ETERNITY NE Quick Start (Printed)
• Wall Mounting Template
Installing Optional Modules
GSM/UMTS Module
• Unpack the GSM/UMTS Module.
• Make sure power supply is turned off before you begin installation.
• Unscrew and remove the top cover of the enclosure. Keep the screws and the cover aside.
• Select the Mobile Port for which you want to install the GSM/UMTS module on the
mainboard. Locate the studs for GSM/UMTS module on the mainboard to install the GSM/
UMTS module.
If you want to use internet for SIP services, you must install 3G module in Mobile Port1 slot. Whether
you install 2G or 3G module in Mobile Port2 slot, it will be used only for voice calls.

Matrix ETERNITY NE Specifications

General

Brand	Matrix
Model	ETERNITY NE
Category	PBX
Language	English
