8.4 Deck removal / Replacement
Figure A
Figure B
1. Remove the front shroud as outlined in
section 8.1
2. Remove four deck screws using a
5mm Allen wrench (Figure A)
3. Remove deck from the running belt
(Figure B )
4. Be careful not to pinch fingers during
removal/installation of deck board
5. *New deck surfaces must ALWAYS be
matched to a new running belt*
