8.14 Handlebar removal / replacement
1. Remove quick key set from machine as outlined in
section 8.12
2. Remove bottom cover from handlebar below using
screwdriver (Figure A)
3. Remove handlebar from the frame (Figure B and C)
Figure B
Figure A
Figure C
