3.4 AUTO CALIBRATION INSTRUCTIONS
Run Auto Calibration to calibrate incline after assembly and after
replacing any electronic component.
AUTO CALIBRATION PROCEDURE:
1) Press and hold the INCLINE DOWN and SPEED DOWN keys
for three seconds until Manager Mode appears on the middle LED
display.
2) Press any UP arrow key and Engineering Mode will appear on the
display.
3) Press ENTER once Engineering Mode is displayed.
4) Scroll between programs in the Engineering Mode using any UP
or DOWN arrow key until Auto Calibration appears on the middle LED
display.
5) Press ENTER once Auto Calibration is displayed., you should not
be standing on the running belt.
6) After completion, the display will state whether the Auto Calibration
passed or failed.
3.5 ALIGNING AND TENSIONING THE RUNNING BELT
After placing the treadmill in the position it will be used, the belt
must be checked for proper tension and centering. The belt may
need to be adjusted after the first 2 hours of use. Temperature,
humidity, and use cause the belt to stretch at different rates. If
the belt starts to slip when a user is on it, be sure to follow the
directions below.
STEP 1: Locate the two hex head bolts on the rear of the treadmill.
The bolts are located at each end of the frame at the back of the
treadmill. These bolts adjust the rear roller. Do not adjust until the
treadmill is on. This will prevent over tightening of one side.
STEP 2: The belt should have equal distance on either side
between the frame. If the belt is touching one side, do not start
the treadmill. Turn the bolts counter clockwise approximately one
full turn on each side. Manually center the belt by pushing the belt
from side to side. Tighten the bolts the same amount as when the
user loosened them, approximately one full turn. Inspect the belt
for damage.
STEP 3: While the treadmill is running at 3 mph, observe the belt
position. If it is moving to the right, tighten the right bolt by turning
it clockwise 1/4 turn, and loosen the left bolt 1/4 turn. If it is moving
to the left, tighten the left bolt by turning it clockwise 1/4 turn and
loosen the right 1/4 turn. Repeat Step 3 until the belt remains
centered for several minutes.
STEP 4: Check the tension of the belt. Set the treadmill speed at
6 mph. While walking in the center of the belt, stomp down hard
with one foot. You should be able to make the belt hesitate slightly.
If you cannot make it hesitate, the tension is too tight. Loosen the
rear roller bolts by turning them counter clockwise by 1/4 turn at a
time. Re-do the stomp test after each turn and continue to loosen
until the belt hesitates. If the belt stops while doing a stomp test,
the belt is too loose. Tighten the rear roller bolts by turning them
clockwise by 1/4 turn at a time. Re-do the stomp test after each
turn and continue to tighten the belt until the belt only hesitates.
CHAPTER 3: PREVENTATIVE MAINTENANCE
